TRL-40(d) 40A, Mini Safety Breaker with Earth Leakage Protection and High Quality

Inquire Now

Description

The TRL-40(d) Mini Safety Breaker is designed to provide optimal earth leakage protection, safeguarding against ground faults. Built with a compact design, this safety breaker is easy to assemble and features a patented design that prioritizes safety and efficiency. Compliant with IEC/EN 61008-1 and GB 16916.1 standards, it ensures reliable performance in various electrical applications.

Specifications

Attribute Details
Product Code TRL-40(d)
Protection Earth leakage protection (Ground fault protection)
Rated Current 16A, 20A, 25A, 32A, 40A
Rated Residual Current Operating, IΔn: 15mA, 30mA
Non-operating, IΔno: 7.5mA, 15mA
Poles 2 poles
Rated Voltage 110V AC, 220V AC
Residual Current Off-Time 0.1s
Standard IEC/EN 61008-1, GB 16916.1
Approval CE, CCC
Type of Trip Ground fault (Electronic)
Rated Switch-On Breaking Capacity, Im 500A
Rated Limited Short Circuit Current, Inc 2.5 KA
Endurance Electrical: 1000 operations
Mechanical: 2000 operations
Material of Body Base: Plastic
Cover in Grey Color: Plastic
Cover in Black Color: Bakelite
Type of Operation AC
Dimensions (L*W*H) 70mm * 32mm * 51mm

Additional Information

  • Compact size for easy installation
  • Designed for enhanced safety features
  • Patented design ensures durability
