TRM2-100, 2 Poles Frame.100 Compact Size Moulded Case Circuit Breaker
Inquire NowDescription
The TRM2-100 Compact Size Moulded Case Circuit Breaker (MCCB) is engineered for optimal protection and performance in low-voltage switchgear and control applications. Designed to meet international standards, including IEC/EN 60947-1 and IEC/EN 60947-2, this circuit breaker ensures reliable operation in various environmental conditions.
This 2-pole MCCB is suitable for environments with ambient temperatures ranging from -5°C to +55°C, with specific considerations for temperatures exceeding 40°C. It operates effectively under relative humidity levels of 45% to 85% and altitudes of up to 2000 meters, ensuring versatility across different installations. The TRM2-100 is classified based on poles and rated current, making it adaptable to various setups.
Specifications
| Attribute | Details |
|---|---|
| Model | TRM2-100 |
| Number of Poles | 2 |
| Rated Current (A) | 100 |
| Rated Voltage (V) | 220/415 |
| Rated Insulated Voltage (V) | 500 |
| Rated Impulse Voltage (kV) | 6 |
| Ultimate Breaking Capability (kA) | 5 (220V), 2.5 (415V) |
| Dimensions (mm) | a: 50, b: 98, c: 60, d: 80 |
| Weight (kg) | 0.41 |
Additional Information
- Ambient Temperature: -5°C to +55°C
- Relative Humidity: 45% – 85%
- Maximum Altitude: 2000 meters
- Circuit breaker must operate in atmospheres free from excessive steam, oil vapors, smoke, dust, and corrosive materials.
