TRM2-100, 3 Poles Frame.100 Compact Size Moulded Case Circuit Breaker
Inquire NowDescription
The TRM2-100 Compact Size Moulded Case Circuit Breaker (MCCB) is designed to provide reliable protection in low-voltage electrical systems. Adhering to international standards, including IEC/EN 60947-1 and IEC/EN 60947-2, this circuit breaker ensures safety and efficiency in diverse applications. The TRM series MCCB is suitable for environments with ambient temperatures ranging from -5°C to +55°C and features a robust design to withstand conditions of relative humidity between 45% and 85%. This compact breaker is available in 2-pole and 3-pole configurations, accommodating various rated currents and applications.
Specifications
| Model | Product Type | Number of Poles | Rated Current (A) | Rated Voltage (V) | Weight (kg) |
|---|---|---|---|---|---|
| TRM2-50/2 | MCCB | 2 | 5, 10, 15, 20, 30, 40, 50 | 220/415 | 0.31 |
| TRM2-50/3 | MCCB | 3 | 5, 10, 15, 20, 30, 40, 50 | 220/415 | 0.41 |
| TRM2-100/2 | MCCB | 2 | 63, 80, 100 | 220/415 | 0.31 |
| TRM2-100/3 | MCCB | 3 | 63, 80, 100 | 220/415 | 0.41 |
Additional Information
- Ultimate Breaking Capability: 6 kV for all models.
- Rated Insulated Voltage: 500V, 50/60Hz for all models.
- Usage Conditions: Designed for use in environments free from excessive steam, oil, smoke, dust, and corrosive materials.
