The Casting Turntable TD1100-90UA01 is engineered for excellence, combining robust construction with precision performance. Made from high-quality QT5007 Iron, this turntable is designed to support a rated payload of 15 tons. Its impressive dimensions, with an overall length of 1100mm and height of 90mm, make it versatile for various applications. The double ball race structure ensures smooth operation, while the carefully designed bearing diameters of 16mm and 22mm enhance stability and efficiency.
This turntable stands out not just for its strength, but also for its superior standards. The radial and axial clearances exceed European regulations, guaranteeing optimal performance. With a flatness measurement of less than 0.15mm and exceptional surface roughness values of Ra only 0.8μm and 3.2μm, it ensures precision and reliability in every rotation. Additionally, its two-course dust-proof design effectively protects against dirt accumulation, enhancing longevity and performance.
Specifications
| Attribute | Details |
|---|---|
| Product Name | Casting Turntable |
| Type | TD1100-90UA01 |
| Overall Length | 1100 mm |
| Overall Height | 90 mm |
| Material | QT5007 Iron |
| Rated Payload | 15 Ton |
| Weight | 100 kg |
| Structure | Double Ball Race |
| Bearing Diameter | 16 mm, 22 mm |
Additional Information
- Warranty: 15-month warranty from the shipping date
- Performance Standards: Radial and axial clearances exceed European standards
- Flatness: Less than 0.15 mm
- Ball Rail Roughness: Ra 0.8 μm
- Surface Roughness: Ra 3.2 μm
- Dust Protection: Features a two-course dust-proof design
- Load Capacity: Exceeds rated standards
