Two cylinder 2 in “V” air cooled diesel engine
Inquire NowDescription
20kw Two Cylinder 2 in “V” Air Cooled Diesel Engine is designed for optimal performance and efficiency. This robust engine features a two-cylinder, 4-stroke design that ensures reliable power output for various applications. With a displacement capacity of 1326cc and a rated output of 20kw, this engine is ideal for industrial uses where durability and efficiency are paramount. Its direct injection combustion system enhances fuel efficiency, making it a cost-effective choice for your power needs.
Specifications
| Model 型号 | HR2V98F |
|---|---|
| Type 动力形式 | Two-cylinder, 2 in “V”, 4-stroke air-cooled diesel |
| Combustion System 燃油系统 | Direct Injection 直喷式 |
| Bore & Stroke (mm) 缸径 & 行程 | 98 × 88 |
| Displacement capacity (cc) 排量 | 1326 |
| Speed (rpm) 转速 | 3000 |
| Rated output (kw) 额定功率 | 20 |
| Max output (kw) 最大功率 | 22 |
| Horse power (hp) 马力 | 30 |
| Fuel 燃油 | 0# (Summer) -10# (Winter) -20# (Cold Winter) -35# (Cold Winter) Light diesel oil |
| Lubrication oil volume (l) 润滑油容量 | 4 |
| Fuel oil consumption rate (g/kw.h) 油耗 | 240 |
| Power output 动力输出 | Crankshaft 曲轴输出 |
| Starting system 启动系统 | Electric 电启动 |
| Dimension (mm) 包装尺寸 | 570 × 580 × 660 |
| Gross weight (kg) 毛重 | 90 |
