type 1000 stick noodle production line
Inquire NowDescription
The Type 1000 Stick Noodle Production Line is an advanced automated system designed for the efficient production of stick noodles. With a remarkable output capacity of 48 tons per 24 hours, this production line is engineered for high performance and reliability. It features nine pairs of roller mechanisms that ensure optimal shaping of noodles, accommodating specifications for both square and round shapes. The adjustable noodle lengths range from 200mm to 240mm, making it versatile for various culinary needs.
This production line is equipped with a comprehensive set of components, including a brine mixer, brine measuring device, dual-axis dough mixer with frequency control, aging machine, and a new-type drying system. The automatic down-shelf and single blade cutter enhance operational efficiency, ensuring a seamless production process.
Designed with technical advantages such as low building costs, high thermal efficiency, and low energy consumption, the Type 1000 production line guarantees stable operation and excellent drying process control, resulting in superior product quality.
Specifications
| Attribute | Details |
|---|---|
| Output | 48T/24h |
| Roller Pairs | 9 pairs |
| Total Power | Around 135 kW |
| Stick Noodles Specification | Square: width 1mm–6mm, thickness 0.8mm–1mm; Round: ф1mm–1.5mm |
| Stick Noodle Length | 200mm, 240mm (adjustable) |
| Drying Time | 4h–4.5h |
Additional Information
This production line not only enhances the production technology of Chinese stick noodles but also aligns with governmental policies aimed at improving agricultural product processing and increasing the value of wheat. The operational efficiency and product quality improvements it offers make it an invaluable asset for traditional stick noodle production enterprises.
