UBM 550 Ultimate Building Steel Structure Building Machine
Inquire NowDescription
The UBM 550 Ultimate Building Steel Structure Building Machine is an innovative mobile factory designed for the on-site production of steel structure buildings. It transforms steel coils into durable building panels, enabling construction teams to efficiently create various arc and gable-shaped structures directly at the construction site. This advanced machine integrates a roller press forming system that streamlines the processes of forming, bending, and cutting to produce finished panels ready for assembly. The patented electric seaming technology ensures waterproof connections without the need for bolts or fasteners, enhancing the integrity of the structures built.
With three generations of equipment upgrades, the UBM 550 significantly reduces labor costs and increases production speed. The first generation introduced a two-step production process, while subsequent generations optimized efficiency through one-step operations and advanced handling features, allowing for easier transportation and installation of panels. This machine supports a variety of applications, including insulation, electrical systems, and HVAC installations, making it a versatile solution for modern construction needs.
Specifications
| Main Type | Feeding Width | Effective Width | Groove Depth | Thickness | Proper Span | Usage Rate |
|---|---|---|---|---|---|---|
| SX-600-305 | 600mm | 305mm | 109mm | 0.6-1.5mm | ≤26/18m | 51% |
| SX-625-330 | 625mm | 330mm | 108mm | 0.6-1.5mm | ≤26/18m | 53% |
| SX-914-610 | 914mm | 610mm | 203mm | 0.8-1.5mm | ≤36/20m | 67% |
| SX-1000-400 | 1000mm | 400mm | 253mm | 0.8-1.5mm | ≤40/28m | 40% |
| SX-1000-550 | 1000mm | 550mm | 187mm | 0.8-1.5mm | ≤36/20m | 55% |
| SX-1000-630 | 1000mm | 630mm | 225mm | 0.8-1.5mm | ≤38/22m | 63% |
| SX-1000-680 | 1000mm | 680mm | 223mm | 0.8-1.5mm | ≤30/15m | 68% |
| SX-1250-500 | 1250mm | 500mm | 295mm | 0.8-1.5mm | ≤45/30m | 40% |
Additional Information
Invention Patent Number: ZL 201010569504.7
This machine provides a comprehensive solution for modern building needs, combining efficiency, durability, and versatility, making it an essential tool for construction professionals.
