Description

The Universal K1 Pulse Servo Drive 2.2kW is a state-of-the-art motion control solution designed for high-performance applications. This intelligent servo drive features a powerful internal position mode that enables continuous multi-path planning, allowing for enhanced motion control flexibility. With support for up to 32 data sets, users can customize each set based on the required number of pulses or angles. The internal position mode also offers adjustable speed, acceleration, deceleration, and emergency deceleration settings, ensuring optimal system performance.

Stability is a key highlight of the Universal K1, as it includes mechanical resonance frequency analysis and two sets of adjustable trap filters, which can operate at frequencies between 50 to 5000 Hz. This effectively mitigates low-frequency resonance and mechanical vibration, with adjustable damping settings for enhanced control at vibration frequencies from 1 to 100 Hz.

Furthermore, the servo drive incorporates multifunctional features such as frictional torque compensation, which minimizes the impact of static friction during mechanical commutation, thus improving command-following performance at low speeds. It also supports multi-bus communication via CANopen, making it versatile for various industrial applications. The system is user-friendly, equipped with debugging software and tools for mechanical characteristics analysis, parameter setting, and monitoring, ensuring intuitive operation.

Specifications

Additional Information

• Automatic determination of load inertial mechanical properties for optimal gain settings
• Easy to operate with support for debugging software and parameter monitoring
