OEM ODM Ventilation duct production line
Description
The Ventilation Duct Production Line is an essential machine for any duct shop, designed to streamline the production of duct blanks. Whether utilized as a stand-alone unit or integrated into a comprehensive Sheet Metal Forming line, this auto duct line offers versatility and efficiency. The AUTO-LINE V is equipped to remove coil set, bead, and notch for both two-piece and wrap ducts, featuring a cut-off process that operates in a feed-to-stop shearing manner. With no minimum cut length or notch spacing requirements, it provides unparalleled flexibility in duct production.
Advanced PC-based controls guarantee consistent quality in leg lengths and feeds, ensuring that only a single operator is needed to manage the entire process. The AUTO-LINE V consists of a robust feeding metal frame, leveler grooving roll, hydraulic notch and punch machine, shearer, movable Pittsburgh lock machine, duplex transverse duct flange machine, TDF folder, and a CNC control system. This combination of features not only enhances performance but also saves space while expanding production capabilities.
Specifications
| Feature | Details |
|---|---|
| Machine Type | Auto Duct Line V |
| Functionality | Produces duct blanks, removes coil set, bead, and notch |
| Cut-off Process | Feed-to-stop shearing |
| Minimum Cut Length | None |
| Notch Spacing Minimum | None |
| Control System | PC-based |
| Operator Requirement | Single operator |
| Included Components | Feeding metal frame, leveler grooving roll, hydraulic notch and punch machine, shearer, movable Pittsburgh lock machine, duplex transverse duct flange machine, TDF folder, CNC control system |
