Description
The Weichai WD615 diesel engine stands out as a powerful 300hp engine designed specifically to drive a 200kW 250kVA generator. This engine is part of the renowned Steyr series, blending advanced technology with exceptional durability. Its new compact design allows for easier installation and transport, making it a preferred choice for various applications.
- Leading Performance: This engine sets the standard with industry-leading indicators of mean effective pressure and power.
- Enhanced Fuel Efficiency: Equipped with improved water filters, it ensures cleaner fuel, thus protecting the injector and high-pressure pump, extending their lifespan.
- Advanced Sealing Techniques: Special piston ring and valve sealing methods significantly reduce fuel consumption rates.
- Durability: The high-pressure forged components, coupled with hardening treatments, enhance fatigue strength and wear resistance, ensuring longevity.
- Long Overhaul Interval: Designed for durability, the engine boasts an overhaul period exceeding 10,000 hours.
Specifications
| Model | Type | Aspiration | Displacement (Liter) | Bore*Stroke (mm) | KW@1500rpm | KW@1800rpm | Dimension (mm) | Net weight (kg) |
|---|---|---|---|---|---|---|---|---|
| K4100D | L 4 | NA | 3.61 | 100×115 | 30.1 | 36 | 950*660*950 | 330 |
| K4100ZD | L 4 | TC | 3.61 | 100×115 | 41.2 | 47 | 950*660*980 | 340 |
| K4102ZD | L 4 | TC | 3.76 | 102×115 | 45 | 50 | 950*660*980 | 360 |
| R4105ZD | L 4 | TC | 4.33 | 105×125 | 56 | 67 | 950*750*1080 | 435 |
| R6105ZD | L 6 | TC | 6.49 | 105×125 | 84 | 90 | 1190*750*1190 | 580 |
| R6105AZLD | L 6 | TI | 6.75 | 105×130 | 110 | 125 | 1280*780*1190 | 620 |
| R6105IZLD | L 6 | TI | 7.10 | 105×135 | 135 | 145 | 1280*780*1190 | 620 |
| HD6126ZLD | L 6 | TI | 9.726 | 126×130 | 235 | 235 | 2230*780*1539 | 950 |
| HD12ZLD | L 6 | TI | 11.596 | 126×155 | 288 | 301 | 2230*780*1539 | 1100 |
Additional Information
For optimal performance, regular maintenance is recommended, including timely oil changes and filter replacements. Ensuring the engine operates under recommended conditions will prolong its service life and efficiency.
