OEM ODM Wheel Loader-ZL50D-II
Description
The Wheel Loader ZL50D-II is a powerhouse designed for efficiency and reliability in heavy-duty applications. Equipped with a robust WEICHAI engine, it offers high horsepower combined with low fuel consumption, making it an ideal choice for construction and industrial tasks. The single-stage four units hydraulic converter and a planet-type force assist gearbox ensure smooth torque moment output, while the fully hydraulic steering system provides easy maneuverability with a small turning radius and stable performance.
This loader features a double-pump combined system for high efficiency and energy conservation, enhancing its motive ability. With a box-type structure for both front and rear chassis, the ZL50D-II boasts exceptional durability. Its modular design optimizes the combination of units, extending the transmission system’s lifespan and ensuring a more logical machine configuration.
The integrated control panel with a streamlined design and new electronic instruments allows operators to monitor machine conditions promptly. Additionally, the loader offers sound and heat insulation, a wide view, and exquisite manual work protection, making it user-friendly and efficient.
Specifications
| Attribute | Unit | Value |
|---|---|---|
| Model | ZL50D-II | |
| Total weight | kg | 16500 |
| Bucket capacity | m3 | 3 |
| Rated load | kg | 5000 |
| Movable arm lifting time | S | ≤6.8 |
| Three item time | S | ≤11.8 |
| Max digging force | kN | ≥145 |
| Min turning radius | mm | 5900 |
| Forward I gear | km/h | 0~11.5 |
| Forward II gear | km/h | 0~36 |
| Reverse gear | km/h | 0~16 |
| Max slope angle | ° | 25 |
| Damping height | mm | 3050 |
| Damping reach | mm | 1290 |
| Overall length | mm | 7880 |
| Overall width | mm | 2990 |
| Overall height | mm | 3400 |
| Engine model | WD615G220 | |
| Engine rated power | kW | 162 |
| Fuel tank capacity | L | 220 |
| Hydraulic oil tank capacity | L | 220 |
