WIRE MESH WELDING MACHINE LINE GWCP2800JZ
Inquire NowDescription
The WIRE MESH WELDING MACHINE LINE GWCP2800JZ is a state-of-the-art CNC control automatic mesh welding machine designed for efficiency and precision in wire mesh production. Suitable for both coil and pre-cut materials, this robust machine offers unparalleled flexibility, accommodating line wires ranging from Ф5 to Ф12mm and cross wires from Ф5 to Ф12mm. With a minimum line wire spacing of 100mm and a maximum welding speed of up to 90 cross wires per minute, it is engineered for high productivity.
Equipped with advanced CNC PLC control and driven by a reliable servo-motor, this machine ensures consistent performance. The welding system comprises 28 welding electrodes, 28 air cylinders for welding press, and 14 water-cooled welding transformers, all integrated with a thermostat for optimal temperature regulation. Additionally, the machine features a mesh puller, cutter, turner, and stacking system to streamline operations.
Control and monitoring are made easy through a user-friendly touch screen console, and customization options are available to meet specific production needs.
Specifications
| Feature | Details |
|---|---|
| Control Type | CNC Control |
| Line Wire Diameter | Ф5-12mm (pre-cut and coil) |
| Cross Wire Diameter | Ф5-12mm (pre-cut) |
| Minimum Line Wire Spacing | 100mm (above 50mm multiples) |
| Maximum Welding Speed | 90 cross wires per minute |
| Welding System Components | 28 welding electrodes, 28 air cylinders, 14 welding transformers |
| Cooling System | Water cooling with thermostat |
| Additional Features | Mesh puller, cutter, turner & stacking system |
| Control Console | Touch screen |
| Customization | Available |
