WQ
Inquire NowDescription
The WQ pump is a high-performance solution designed for efficient drainage and sewage management in both domestic and civil applications. With a remarkable flow rate of up to 1800L/min and a head of up to 35 meters, this pump excels in handling dirty water and sewage. It is engineered to operate under challenging conditions, including a maximum submersion depth of 5 meters and liquid temperatures reaching up to +40℃. The WQ pump features a robust design, equipped with a single-channel impeller that can handle suspended solids up to 35mm in size, making it ideal for clearing surface water or pumping wastewater from residential properties.
Specifications
| Feature | Specification |
|---|---|
| Flow Rate | Up to 1800L/min |
| Head | Up to 35 m |
| Submersion Depth | 5 m |
| Liquid Temperature | Up to +40℃ |
| Ambient Temperature | Up to +40℃ |
| Max Working Pressure | 6 bar |
| Passage of Suspended Solids | Up to 35 mm |
| Pump Body Material | Cast Iron |
| Motor Bracket Material | Cast Iron |
| Impeller Material | Cast Iron |
| Motor Shaft Material | SS 420 or CS45# |
| Mechanical Seal | Ceramic-Graphite, Silicon Carbide-Carbide Alloy |
| Electric Motor | Single |
Additional Information
- Designed for reliable operation in flooded installations with automatic operation.
- Ideal for draining sewage and wastewater in various settings.
