XCMG Official small bulldozers TY160 China new 160hp crawler bulldozer machine for sale
Inquire NowDescription
The TY160 crawler bulldozer is a robust machine designed for superior performance in various construction tasks. With a powerful 160hp engine, this bulldozer combines reliability with efficiency, ensuring a long service life. By integrating advanced Japanese D65A-8 technology and leveraging the strengths of the D60A-8 model, the TY160 has been meticulously crafted through domestic design innovations.
This bulldozer features an optimized design, providing not only aesthetic appeal but also enhanced functionality. The powerful engine ensures high torque output and low fuel consumption, making it an excellent choice for heavy-duty applications. With hydraulically powered controls and automatic gear shifting capabilities, operators can experience seamless operation without interruptions.
Key features include:
- High engine power reserve for demanding tasks.
- Efficient torque converter design for maximum performance.
- A well-structured cab with exceptional visibility and comfort.
Specifications
| Name | Specifications |
|---|---|
| Overall size of the machine (mm) | 5128×3416×3120 (Straight shovel, traction rod) |
| Overall size of the machine (mm) | 6215×3416×3120 (Straight shovel, three toothed soil loosen) |
| The use quality of the whole machine (kg) | 17100 (Straight shovel, traction rod) |
| The use quality of the whole machine (kg) | 18700 (Straight shovel, three toothed soil loosen) |
| Maximum traction power (kN) | 148 |
| Minimum turning radius (mm) | 3100 |
| Maximum climbing performance (°) | 30 |
| Minimum ground clearance (mm) | No crawler (400) |
| Average ground specific pressure (MPa) | 0.065 |
| Tracked ground length (mm) | 2430 |
| Caterpillar center distance (mm) | 1880 |
| Production efficiency (m3/h) | Data not specified |
Additional Information
The TY160 crawler bulldozer is engineered to tackle various terrains and conditions, making it ideal for construction, mining, and agricultural applications. Its advanced features ensure high operational efficiency and user-friendly handling, providing a strategic advantage on the job site.
