XDL21-CP42 rubber cap button rubber push button waterproof pushbutton switch
Inquire NowDescription
The XDL21-CP42 Rubber Cap Button is a robust and waterproof pushbutton switch designed for reliability in controlling circuits. This versatile switch can handle AC voltages of up to 660V at 50Hz or 60Hz and DC voltages below 400V, making it ideal for both signal control and interlocking applications. Constructed from durable zinc alloy and high-grade anti-flame plastic, this pushbutton switch features contacts made from special silver alloy, providing excellent resistance to electrical erosion. The series also includes signal lamps engineered for electrical appliances with an AC voltage of up to 380V and DC voltage below 380V, perfect for indicating, warning, or emergency signals. All products comply with GB/T14048.1 and IEC60947-5-1 standards and are certified by CE, ISO9001, ROHS, and UL for safety and quality assurance.
Specifications
| Parameter | Pushbutton | Signal Lamp |
|---|---|---|
| Rated insulation | AC 600V (50Hz/60Hz) | Insulation resistance |
| Conventional heating current | 10A | Contact resistance |
| Insulation resistance | ≥50MΩ | Pf withstand voltage |
| Contact resistance | ≤25MinΩ | Voltage wave |
| Mechanical life | 100×10,000 pushbutton | Brightness |
| Electrical life | 500×10,000 pushbutton | Continuous working life |
Additional Information
The XDL21-CP42 switch is engineered for long-lasting performance with a mechanical life of 100,000 cycles and an electrical life of 500,000 cycles. The continuous working life is rated at 10,000 hours, ensuring reliability across various applications.
