XDL21-EA31 waterproof pushbutton switch plastic 22mm elevator pushbutton
Inquire NowDescription
The XDL21-EA31 is a robust and reliable waterproof pushbutton switch designed specifically for elevator applications. With a diameter of 22mm, this switch ensures optimal performance in controlling AC voltage circuits up to 660V at either 50Hz or 60Hz, as well as DC voltage circuits below 400V. Its construction features a durable zinc alloy body and high-grade anti-flame plastic, providing excellent resistance against electrical erosion thanks to the specialized silver alloy contacts. This pushbutton is not only ideal for controlling signals but also fulfills interlocking purposes, making it a versatile component in electrical systems.
Designed to meet rigorous standards, the XDL21-EA31 complies with GB/T14048.1 and IEC60947-5-1, and is certified by CE, ISO9001, ROHS, and UL, ensuring quality and safety in operation. The unit’s signal lamp series operates effectively with electrical appliances, handling AC voltage up to 380V and DC voltage below 380V, making it suitable for indicating signals, warning signals, and emergency signals.
Specifications
| Feature | Pushbutton | Signal Lamp |
|---|---|---|
| Rated Insulation | AC 600V (50Hz/60Hz) | Insulation Resistance |
| Conventional Heating Current | 10A | Contact Resistance |
| Insulation Resistance | ≥50MΩ | Pf Withstand Voltage |
| Contact Resistance | ≤25MinΩ | Voltage Wave |
| Mechanical Life | 100×10000 pushes | Brightness |
| Electrical Life | 500×10000 pushes | Continuous Working Life |
| – | – | 10x10000h |
Additional Information
- Certification: CE, ISO9001, ROHS, UL Certified
- Applications: Suitable for controlling signals, warning signals, and emergency signals in various electrical circuits.
