XDL21-EA4322 plastic symbol industrial electric water proof pushbutton switch
Inquire NowDescription
The XDL21-EA4322 is a highly efficient plastic symbol industrial electric waterproof pushbutton switch designed for robust performance in various applications. This versatile switch is ideal for controlling circuits of AC voltage up to 660V at 50Hz or 60Hz and DC voltage below 400V. It excels in signal control and interlocking purposes, ensuring reliable operation in demanding environments. The pushbutton features a main body made of durable zinc alloy combined with high-grade anti-flame plastic, while the contacts utilize a special silver alloy, providing exceptional resistance to electrical erosion. Additionally, the accompanying signal lamp series is suitable for electrical appliances operating at AC voltages up to 380V and DC voltages below 380V, making it perfect for indicating signals, warning signals, and emergency signals. All products comply with GB/T14048.1 and IEC60947-5-1 standards, and are CE, ISO9001, ROHS, and UL certified.
Specifications
| Feature | Pushbutton Switch | Signal Lamp |
|---|---|---|
| Rated Insulation | AC 600V (50Hz/60Hz) | Insulation Resistance |
| Conventional Heating Current | 10A | Contact Resistance |
| Insulation Resistance | ≥50MΩ | Voltage Wave |
| Mechanical Life | 100×10,000 pushbutton | Brightness |
| Electrical Life | 500×10,000 pushbutton | Continuous Working Life |
Additional Information
- Mechanical life: 100×10,000 pushbutton; 50×10,000 selector switch
- Electrical life: 500×10,000 pushbutton; 25×10,000 selector switch
- Continuous working life: 10×10,000 hours
