XDL21-EW3561 industrial waterproof plastic flush indicator light pushbutton switches
Inquire NowDescription
The XDL21-EW3561 industrial waterproof plastic flush indicator light pushbutton switches are engineered for robust performance in demanding environments. These pushbuttons provide reliable control for AC voltage circuits up to 660V at either 50Hz or 60Hz, as well as DC voltages below 400V. With a sturdy zinc alloy body and high-grade anti-flame plastic, these switches ensure durability and safety. The specially designed silver alloy contacts resist electrical erosion, enhancing longevity and reliability.
These switches are not only practical but also versatile, serving as control signals for various applications including warning and emergency signals. They are suitable for circuits up to 380V for AC and below 380V for DC. Each product adheres to international standards, including GB/T14048.1 and IEC60947-5-1, and carries important certifications such as CE, ISO9001, ROHS, and UL.
Specifications
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated insulation | AC 600V (50Hz/60Hz) | Insulation resistance | ≥50MΩ |
| Conventional heating current | 10A | Contact resistance | ≤25MinΩ |
| Pf withstand voltage | AC 2.5KV/min | Voltage wave | ±20% |
| Mechanical life | 100×10000 pushbutton | Brightness | 60cd/m² |
| Electrical life | 500×10000 pushbutton | Continuous working life | 10x10000h |
Additional Information
- Ideal for use as indicating signals, warning signals, and emergency signals.
- All products are certified according to CE, ISO9001, ROHS, and UL standards.
