XINYA 24L oil lubricated piston direct-driven air compressor (XYBM24)
Inquire NowDescription
The XINYA 24L Oil Lubricated Piston Direct-Driven Air Compressor (Model: XYBM24) is engineered for high-performance and durability, making it an ideal choice for various applications, from automotive repair to woodworking. It features an induction motor compatible with both 127V and 230V, ensuring versatility in different settings. The compressor is equipped with a thermal protection system that safeguards the motor from overheating, while its aluminum cylinder head and crankcase enhance heat dissipation, prolonging its lifespan.
This robust air compressor boasts a durable cast iron cylinder and lightweight aluminum piston, complete with high alloy piston rings for optimal loading capacity. The user-friendly design includes an easy-open drain valve, a pressure switch with adjustable cut-in and cut-off settings, and a regulator with a gauge for precise pressure monitoring. Transporting the compressor is effortless thanks to its convenient carry handle, while the plastic coating tank ensures corrosion resistance.
Specifications
| Model | XYBM24 |
|---|---|
| Voltage | 220V |
| Frequency | 50HZ |
| Motor | 1.2KW (1.5HP) |
| Tank Capacity | 24L |
| Cylinder Diameter | 47mm |
| Piston Count | 1 pc |
| Max Air Flow | 188L/min (6.6cfm) |
| Speed | 2850 r.p.m |
| Max Pressure | 8bar (115psi) |
Additional Information
- Induction motor with dual voltage compatibility (127V and 230V).
- Motor equipped with a thermal protection system for safety.
- Constructed with an aluminum cylinder head and crankcase for enhanced cooling.
- Durable cast iron cylinder designed for long-lasting performance.
- Quick connector available for easy attachment of tools.
