Y2 THREE PHASE CAST IRON MOTOR
Inquire NowDescription
The Y2 Three Phase Cast Iron Motor is designed to meet national standards, including IEC34-1 and JB/T 8680.1-1998, ensuring reliability and efficiency in various applications. This motor features a robust construction, offering an aesthetically pleasing design with minimal vibration and low noise levels. With a protection class of IP44/IP55 and insulation classes F/H, it is built to withstand demanding environments, making it ideal for industrial use.
Operating under conditions where the ambient temperature ranges from -15℃ to 40℃ and altitudes not exceeding 1000 meters, this motor is versatile and adaptable. It supports rated voltages of 380V or any voltage between 220V and 760V, catering to diverse operational requirements. The Y2 motor is suitable for continuous duty (S1) and utilizes star connection for up to 3KW and delta connection for 4KW and above.
Specifications
| Attribute | Details |
|---|---|
| Protection Class | IP44 / IP55 |
| Insulation Class | F / H |
| Cooling Method | ICO141 |
| Operating Temperature | -15℃ to 40℃ |
| Altitude | Not exceeding 1000 m |
| Rated Voltage | 380V or 220V – 760V |
| Duty | S1 (Continuous) |
| Connection | Star connection (up to 3KW), Delta connection (4KW and above) |
