YB-50/80
Inquire NowDescription
The YB Series Rotary Vane Blackmer Pump is a cutting-edge sliding vane pump designed for efficiency and reliability in the transfer of various liquids. Engineered with a built-in by-pass valve, this pump utilizes a rotor equipped with sliding vanes to ensure smooth liquid movement. Constructed from durable nodular cast iron and featuring self-lubricating vanes, it excels in handling viscous and volatile liquids while consuming less horsepower compared to traditional pumps. Its inherent advantage lies in the capability to transmit high flow rates at low revolutions, making it a perfect solution for industrial applications.
Features:
- Excellent self-priming and dry run capabilities.
- Versatile applications for diesel, gasoline, lubricating oil, heavy oil, and more.
- Easy maintenance with replaceable vanes without the need to move the entire pump.
- High flow rate speed options available.
Specifications
| Model | Size | Nominal Flowrate (G/min) | Nominal Flowrate (L/min) | Pump Speed (R/min) | Power (HP) | Power (KW) | Viscosity (SUU) | Viscosity (CP) | Working Pressure (PSI) | Working Pressure (Bar) |
|---|---|---|---|---|---|---|---|---|---|---|
| YB-50 | 50mm/2″ | 87 | 329 | 780 | 3 | 2.2 | 20,000 | 175 | 4,250 | 12.1 |
| YB-65 | 65mm/2.5″ | 157 | 594 | 780 | 5 | 4 | ||||
| YB-80 | 80mm/3″ | 270 | 1,022 | 640 | 10 | 7.5 | ||||
| YB-100 | 100mm/4″ | 505 | 1,900 | 500 | 25 | 18.5 |
Additional Information
Please ensure to follow maintenance guidelines for optimal performance and longevity of the pump. Regular checks on the vane condition and lubrication can enhance its operational efficiency.
