Description
The YLK168F is a robust and reliable engine designed for various applications. This single-cylinder, 4-stroke engine is forced air cooled, ensuring optimal performance even in demanding conditions. With a displacement of 163 ml and a compression ratio of 6:1, it offers a rated output of 2.6 kW at 3600 rpm, making it suitable for a wide range of machinery and equipment. The manual starting mechanism and non-contact transistorized ignition provide ease of use and reliability. The YLK168F is designed to operate efficiently with a fuel capacity of 3.6 liters and can utilize both 90# gasoline and kerosene. Its compact dimensions and lightweight design make it an excellent choice for portable applications.
Specifications
| Model | YLK168F |
|---|---|
| Engine Type | Single cylinder, 4-stroke, forced air cooled |
| Bore x Stroke (mm) | 68 x 45 |
| Displacement (ml) | 163 |
| Compression Ratio | 6:1 |
| Rated Output (kW) / 3600 rpm | 2.6 |
| Max. Torque (N·m / 2500 rpm) | 74 |
| Ignition Fashion | Non-contact transistorized ignition |
| Starting Fashion | Manual |
| Fuel Capacity (L) | 3.6 |
| Gasoline Capacity (L) | 0.4 |
| Oil Capacity (L) | 0.6 |
| Fuel Trademark | 90# Gasoline, Kerosene |
| Oil Trademark | 15W/40 SAE |
| Noise (dB at 1 meter) | ≤104 |
| Idle Speed (rpm) | 1350 |
| Dimension (mm) | 312 x 362 x 335 |
| Dry Weight (kg) | 16 |
