YW-693102
Inquire NowDescription
The YW-693102 is a high-performance 6″×9″ 3-way speaker system designed for audio enthusiasts seeking powerful sound quality. Featuring a robust 6″×9″ IMPP cone and a 40mm midrange driver, it ensures rich mid frequencies, while the 15mm piezo tweeter delivers clear high frequencies. With a maximum power handling of 200W, this speaker is engineered to elevate your listening experience, whether in your car or home audio setup. Its impressive frequency response of 70Hz to 22kHz ensures that you hear every detail in your music, making it a fantastic choice for anyone serious about sound.
Specifications
Feature | Details |
---|---|
Model | YW-693102 |
Type | 3-way speaker system |
Dimensions | 6″×9″ |
Midrange Cone | 6″×9″ IMPP |
Midrange Size | 40mm |
Tweeter Size | 15mm Piezo |
Max Power | 200W |
Impedance | 4Ω |
Frequency Response | 70 – 22000 Hz |
S.P.L (db/w/m) | 91 db |
Voice Coil | 1″ |
Magnet Size | φ100mm×18mm |
Additional Information
- Ideal for both automotive and home audio applications
- Designed for clarity and warmth across a wide range of frequencies
