Zoom BOX Camera-SFL6004
Inquire NowDescription
The Zoom BOX Camera-SFL6004 is a sophisticated surveillance solution designed to capture high-quality video in various environments. Equipped with a 1/4″ Sony CCD image sensor, it seamlessly operates in both PAL and NTSC systems, ensuring compatibility with a wide range of devices. This camera is ideal for both indoor and outdoor usage, featuring an impressive 22X auto-focus zoom lens that allows for detailed imagery even at a distance.
With a minimum illumination of 0.80LUX (F1.2) and 0Lux when the LED is activated, the SFL6004 excels in low-light conditions, making it suitable for 24/7 monitoring. The camera’s horizontal resolution of 420TVL and a signal-to-noise ratio of >=48dB provide clear and crisp video quality, while its electronic shutter capable of 1/50 – 1/10,0000S enhances its versatility in various lighting conditions.
Designed for resilience, the SFL6004 can operate in extreme temperatures ranging from -10°C to 50°C and withstand humidity levels of up to 95% RH, ensuring reliable performance in challenging outdoor environments. This camera is an exceptional choice for users looking for advanced surveillance capabilities combined with robust build quality.
Specifications
| Model | SFL6004 |
|---|---|
| System | PAL / NTSC |
| Image Sensor | 1/4″ Sony CCD |
| Picture Elements | PAL: 500(H) x 582(V); NTSC: 510(H) x 494(V) |
| Video Output | 1.0Vp-p, 75Ω Composite, BNC x 1 |
| Minimum Illumination | 0.80LUX/F1.2; 0Lux (LED ON) |
| Horizontal Resolution | 420TVL |
| S/N Ratio | >=48dB |
| Electronic Shutter | 1/50 – 1/10,0000S |
| White Balance | Auto |
| Gamma Ratio | >=0.45 |
| Infrared Spectrum | Infrared Sensitive |
| Lens Mount | Auto Focus 22X Zoom Lens |
| Operating Temperature | Outdoor: -10°C to 50°C |
| Humidity | 0 to 95% RH (non-condensing) |
| Sync System | 2:1 interlace internal Sync. |
| Power Supply | 12V DC 750mA |
| Weight | Approx 0.36kg |
Additional Information
- Perfect for both indoor and outdoor surveillance applications.
- High resilience to varying environmental conditions.
